AFCO double pass GM style racing radiator 24″ W x 19″ T offers great fit and performance, along with an optimized fin count ratio for maximum cooling efficiency. ALL AFCO radiators offer a furnace brazed sealed core without the use of epoxy, and are all 100% tested before shipping. AFCO Double Pass provide more cooling over standard type radiators, with less than 2 oz. of added weight. Common temperature drops are 10-20 degrees when replacing a standard configuration radiator of equal core size. Keeps your mind off the water temp and puts it onto the race track. Double pass radiators gain their efficiency by first passing the fluid over the top half of the radiator and then the bottom half, giving the radiator the ability to dissipate heat twice. AFCO uses an exclusive 360 degree TIG-welded baffle that splits the radiator core into two sections. This 360 degree baffle effectively creates two radiators out of one and assures that you won’t have any coolant that has entered the radiator but never made it across the core. This is superior to utilizing silicone to seal internal baffles, or worse, a partial weld that allows the coolant to bypass the radiator core completely. 360 Degree Welded – Internal baffle ensures no “short cuts” past the baffle due to internal leaks. Installation Instructions included.
- MPN: 80127NDP
| Brand | AFCO Racing |
| Manufacturer’s Part Number | 80127NDP |
| Part Type | Radiators |
| Product Line | AFCO Racing Universal Performance Line Radiators |
| Radiator Material | Aluminum |
| Radiator Style | Crossflow |
| Overall Width (in) | 23.500 in. |
| Overall Height (in) | 20.000 in. |
| Overall Thickness (in) | 3.000 in. |
| Inlet Location | Upper passenger side |
| Outlet Location | Lower passenger side |
| Radiator Finish | Natural |
| Core Width (in) | 20.000 in. |
| Core Height (in) | 18.500 in. |
| Core Thickness (in) | 3.000 in. |
| Row Quantity | 2 |
| Transmission Cooler | No |
| Trans Cooler Adapter Fittings Included | No |
| Inlet Size | 1 1/2 in. |
| Outlet Size | 1 3/4 in. |
| Tube Size | 1 in. |
| Fan Included | No |
| Radiator Cap Included | No |
| Quantity | Sold individually. |
| Notes | Double pass design, driver side filler neck. |
